| Status | Obsolete |
| Watts | 20W |
| Volts | 12V |
| Shape | MR16 |
| Filament | C-8 |
| Base | Bayonet Double Contact |
| ANSI Base | BA15d |
| Finish | None |
| CCT (Kelvin) | 2900K |
| Temperature | Warm White |
| CRI | 100 |
| Lumens | 180L |
| Beam Spread | 9 |
| Dimmable | Yes-Dimmable |
| Dimming Note | Check the transformer/driver MFG for dimmer compatibility |
| Hours Rated | 2000 |
| Product Category | MR |
| Lamp Type | MR |
| Technology | Halogen |
| Watts | 20W |
| Volts | 12V |
| Amps | 1.667A |
| Filament | C-8 |
| CCT (Kelvin) | 2900K |
| Temperature | Warm White |
| CRI | 100 |
| Lumens | 180L |
| Beam Spread | 9 |
| Spot Type | NSP - Narrow Spot |
| CBCP | 4100 |
| Dimmable | Yes-Dimmable |
| Dimming Note | Check the transformer/driver MFG for dimmer compatibility |
| Hours Rated | 2000 |
| MOL | 1.88 |
| MOD | 2 |
| Shape | MR16 |
| Base | Bayonet Double Contact |
| ANSI Base | BA15d |
| Finish | None |
| Lensed | Unlensed Lamp |
| Housing Color | Clear |
| Additional Info | UV Block |
| Safety Listing | Not Listed |
| Location Rating | Damp |
| California Status | Non-Compliant |
| Title 20 / 24 Status | Non-Compliant |
| California Prop 65 | Lead |
| RoHS Compliant | Yes |
| SDS Sheet | Halogen Tungsten Lamp |
| Each UPC | 045923019715 |
| Each Quantity | 1 |
| Each Length (in.) | 2.01 |
| Each Width (in.) | 2.01 |
| Each Height (in.) | 2.01 |
| Each Weight (lb.) | 0.09 |
| Each Cube (CuFt.) | 0.0047 |
| Pack Type | Box |
| Inner UPC | 20045923019719 |
| Inner Quantity | 12 |
| Inner Length (in.) | 8.39 |
| Inner Width (in.) | 6.42 |
| Inner Height (in.) | 2.56 |
| Inner Weight (lb.) | 1.17 |
| Inner Cube (CuFt.) | 0.0798 |
| Case UPC | 10045923019712 |
| Case Quantity | 240 |
| Case Length (in.) | 17.34 |
| Case Width (in.) | 13.40 |
| Case Height (in.) | 13.99 |
| Case Weight (lb.) | 23.81 |
| Case Cube (CuFt.) | 1.8812 |
