| Status | Transitioning |
| Substitute | 65-700R1 |
| Fixture Type | Strip Light |
| Finish | White |
| Wattage | 20W |
| Lumen Output | 2735L-2830L |
| CCT (Kelvin) | 3500K/4000K/5000K |
| IP Rating | IP20 |
| Indoor or Outdoor Fixture | Indoor |
| IOT Enabled | No |
| Technology | LED |
| Wattage | 20W |
| Lumen Output | 2735L-2830L |
| CCT (Kelvin) | 3500K/4000K/5000K |
| Color Temperature | Neutral White to Daylight |
| CRI | 80 |
| Voltage | 100V-277V |
| Beam Angle | 120 |
| Rated Hours | 50000 |
| Operating Temperature | -20C (-4F) to +60C (+140F) |
| Dimmable | Yes-Dimmable |
| Dimming Note | 0-10V Dimming Only |
| Photocell or Sensor | Optional Add-On |
| Lens Material | Polycarbonate (PC) |
| Surge Protection | Built-in surge protection - 2KV |
| Weight (lb.) | 1.78 |
| IP Rating | IP20 |
| Material | Steel |
| Height (in.) | 3.27 |
| Width (in.) | 2.95 |
| Length (in.) | 24 |
| Back Plate or Canopy Diameter (in.) | 4.75 |
| Safety Listing | cULus - Certified |
| Location Rating | Damp |
| UL Application | Ceiling / Wall |
| Energy Star | No |
| DLC Approved | Yes |
| DLC ID | PLVT1LBRH9X3; PL5HHJWSKN81 |
| B.U.G. Rating | B1-U3-G1 |
| NSF Approved | No |
| CA T20 / T24 Rationale | T20 Exempt - Fixtures Not Regulated |
| California Prop 65 | Lead |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| Flicker Free | Yes |
| SDS Sheet | LED Fixture |
| Additional Information | Other DLC Listings: PL5HHJWSKN81, Standard, Direct Linear Ambient Luminaires. |
| Specification Note | Add on sensors, 86-202 and 86-211, are only rated for 120-277 Volt |
| Warranty | 5 Year Limited - Fixtures |
| Each UPC | 045923657900 |
| Each Quantity | 1 |
| Each Length (in.) | 26.10 |
| Each Width (in.) | 5.20 |
| Each Height (in.) | 5.31 |
| Each Weight (lb.) | 1.88 |
| Each Cube (CuFt.) | 0.4171 |
| Pack Type | Box |
| Inner Quantity | 0 |
| Inner Length (in.) | 0.00 |
| Inner Width (in.) | 0.00 |
| Inner Height (in.) | 0.00 |
| Inner Weight (lb.) | 0.00 |
| Inner Cube (CuFt.) | 0.0000 |
| Case UPC | 10045923657907 |
| Case Quantity | 8 |
| Case Length (in.) | 26.65 |
| Case Width (in.) | 21.65 |
| Case Height (in.) | 11.81 |
| Case Weight (lb.) | 15.25 |
| Case Cube (CuFt.) | 3.9433 |
