| Status | Active |
| Fixture Type | Backlit Flat Panel |
| Finish | White |
| Wattage | 20W/30W/40W |
| Lumen Output | 2200L-4600L |
| CCT (Kelvin) | 3500K/4000K/5000K |
| IP Rating | IP20 |
| Indoor or Outdoor Fixture | Indoor |
| Panel Size | 1x4 |
| IOT Enabled | No |
| Technology | LED |
| Wattage | 20W/30W/40W |
| Lumen Output | 2200L-4600L |
| CCT (Kelvin) | 3500K/4000K/5000K |
| Color Temperature | Warm to Cool White |
| CRI | 80+ |
| Voltage | 100V-277V |
| Beam Angle | 120 |
| Rated Hours | 50000 |
| Operating Temperature | -17C (+1.4F) to +45C (+113F) |
| Dimmable | Yes-Dimmable |
| Dimming Note | 0-10V Dimming Only |
| Photocell or Sensor | No Photocell |
| Lens Material | Poly methyl methacrylate (PMMA) |
| Surge Protection | Built-in surge protection - 2KV |
| Weight (lb.) | 4.98 |
| IP Rating | IP20 |
| Material | Aluminum / Steel |
| Height (in.) | 3.09 |
| Width (in.) | 11.84 |
| Length (in.) | 47.72 |
| Safety Listing | cETLus - Listed |
| Location Rating | Damp |
| UL Application | LED Panel Luminaire |
| Energy Star | No |
| DLC Approved | Yes |
| DLC ID | S-HLPDJ6 |
| NSF Approved | Yes |
| Air Tight Rated | No |
| IC Rated | Yes |
| CA T20 / T24 Rationale | T20 Exempt - Fixtures Not Regulated |
| California Prop 65 | Lead |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| Flicker Free | Yes |
| SDS Sheet | LED Fixture |
| Additional Information | Driver Specs - VDC38-48V; 430/620/810mA |
| Warranty | 5 Year Limited - Fixtures |
| Each UPC | 045923657191 |
| Each Quantity | 1 |
| Each Length (in.) | 49.02 |
| Each Width (in.) | 2.56 |
| Each Height (in.) | 13.39 |
| Each Weight (lb.) | 6.70 |
| Each Cube (CuFt.) | 0.9724 |
| Pack Type | Box |
| Inner Quantity | 0 |
| Inner Length (in.) | 0.00 |
| Inner Width (in.) | 0.00 |
| Inner Height (in.) | 0.00 |
| Inner Weight (lb.) | 0.00 |
| Inner Cube (CuFt.) | 0.0000 |
| Case UPC | 10045923657198 |
| Case Quantity | 1 |
| Case Length (in.) | 49.02 |
| Case Width (in.) | 2.56 |
| Case Height (in.) | 13.39 |
| Case Weight (lb.) | 6.70 |
| Case Cube (CuFt.) | 0.9724 |
