| Status | Active |
| Fixture Type | Wall Pack |
| Finish | Bronze |
| Wattage | 20W/40W/60W |
| Lumen Output | 3056L-8421L |
| CCT (Kelvin) | 3000K/4000K/5000K |
| Temperature | Soft White to Natural Light |
| IP Rating | IP65 |
| Indoor or Outdoor Fixture | Outdoor |
| Technology | LED |
| Wattage | 20W/40W/60W |
| Lumen Output | 3056L-8421L |
| CCT (Kelvin) | 3000K/4000K/5000K |
| Color Temperature | Soft White to Natural Light |
| CRI | 80+ |
| Voltage | 120V-347V |
| Beam Angle | 108 |
| Rated Hours | 50000 |
| Operating Temperature | -40C (-40F) to +50C (+122F) |
| Dimmable | Yes-Dimmable |
| Dimming Note | 0-10V Dimming |
| Photocell or Sensor | Yes - Bypassable |
| Lens Material | Polycarbonate (PC) |
| Surge Protection | Built-in surge protection - 6KV |
| Weight (lb.) | 7.94 |
| IP Rating | IP65 |
| Material | Die-Cast Aluminum |
| Height (in.) | 9.36 |
| Width (in.) | 10.65 |
| Extension (in.) | 6.85 |
| Safety Listing | cULus |
| Location Rating | Wet |
| DLC Approved | Yes |
| DLC ID | S-45Y2JF |
| B.U.G. Rating | B2-U0-G2 |
| California Prop 65 | Lead |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| Flicker Free | No |
| Specification Note | Type II Light Distribution; For International Dark Sky Compliance the fixture CCT must be set to 3000K and installed in a downward facing and locked position |
| Warranty | 5 Year Limited - Fixtures |
| Each UPC | 045923434150 |
| Each Quantity | 1 |
| Each Length (in.) | 13.27 |
| Each Width (in.) | 12.64 |
| Each Height (in.) | 8.46 |
| Each Weight (lb.) | 9.90 |
| Each Cube (CuFt.) | 0.8212 |
| Pack Type | Box |
| Inner Quantity | 0 |
| Inner Length (in.) | 0.00 |
| Inner Width (in.) | 0.00 |
| Inner Height (in.) | 0.00 |
| Inner Weight (lb.) | 0.00 |
| Inner Cube (CuFt.) | 0.0000 |
| Case UPC | 10045923434157 |
| Case Quantity | 1 |
| Case Length (in.) | 13.27 |
| Case Width (in.) | 12.64 |
| Case Height (in.) | 8.46 |
| Case Weight (lb.) | 9.90 |
| Case Cube (CuFt.) | 0.8212 |
