» 62-1137

62-1137 1 LT LED SM UP OR DOWN SCONCE

62-1137

1 LT LED SM UP OR DOWN SCONCE

1 Light - LED Small Up or Down Sconce -10W - 3000K - White Finish 120-277V


Satco’s 1 light cylindrical small wall sconce is modern, sleek, and contemporary in design. Casting elongated columns of light from both the top and bottom, install this white fixture up to elongate and down highlight. Elegant and stylish, this single light architectural light comes alive when illuminated.
  • Use to emphasize and add importance to the facade of an exterior, walls, gardens, entrances, homes, commercial areas, or to enhance visual guidance towards a building or area.
  • Fixture dimensional specifications (in inches), Height: 6.75, Diameter: 2.38, Width: 4.50, Ext: 3.38
  • Direct Wired installation. Wet rated for outdoor use. Wall mount installation, mounting hardware included.
  • Integrated LED
  • 90 CRI superior quality LED light, rated for 50000 hours, for an energy efficient lighting option.
  • Architectural Outdoor Design
  • 5 year limited warranty. See manufacturer website for details.
Lights

62-1137

1 LT LED SM UP OR DOWN SCONCE

1 Light - LED Small Up or Down Sconce -10W - 3000K - White Finish 120-277V

Satco’s 1 light cylindrical small wall sconce is modern, sleek, and contemporary in design. Casting elongated columns of light from both the top and bottom, install this white fixture up to elongate and down highlight. Elegant and stylish, this single light architectural light comes alive when illuminated.
  • Use to emphasize and add importance to the facade of an exterior, walls, gardens, entrances, homes, commercial areas, or to enhance visual guidance towards a building or area.
  • Fixture dimensional specifications (in inches), Height: 6.75, Diameter: 2.38, Width: 4.50, Ext: 3.38
  • Direct Wired installation. Wet rated for outdoor use. Wall mount installation, mounting hardware included.
  • Integrated LED
  • 90 CRI superior quality LED light, rated for 50000 hours, for an energy efficient lighting option.
  • Architectural Outdoor Design
  • 5 year limited warranty. See manufacturer website for details.

Specifications

General
StatusActive
FinishWhite
Wattage10W
StyleUtility
CCT (Kelvin)3000K
Color TemperatureWarm White
Width (in.)4.53
Height (in.)6.77
Extension (in.)3.43
Indoor or Outdoor FixtureOutdoor
Specifications
TechnologyLED
Wattage10W
CCT (Kelvin)3000K
Color TemperatureWarm White
CRI90
Lumen Output900L
Rated Hours50000
Voltage120V/277V
DimmableNon-Dimmable
Photocell or SensorNo Photocell
Weight (lb.)1.72
Up/Down InstallationUp or Down
Fixture MaterialDie Cast Aluminum
Fixture TypeSconce
Operating Temperature-30C (-22F) to +50C (+122F)
Dimensions
Height (in.)6.77
Width (in.)4.53
Extension (in.)3.43
Back Plate or Canopy Width (in.)4.53
Back Plate or Canopy Height (in.)4.53
Compliance
Safety ListingcULus - Listed
Location RatingWet
UL ApplicationOutdoor
Energy StarYes
ES Unique IDESID-2336404
ADA CompliantYes
B.U.G. RatingB1-U1-G0
Dark Sky CompliantYes
CA T20 / T24 RationaleCalifornia T24 2016 & 2019 JA8 Compliant; T20 Exempt - Fixtures Not Regulated
California StatusLawful for sale in California
Title 20 / 24 StatusCalifornia T24 Compliant
California Prop 65
RoHS CompliantYes
FCC CompliantYes
SDS SheetLED Fixture
Additional Information
Specification NoteFor International Dark Sky compliance, the fixture CCT must be set to 3000K and installed in a downward facing and locked position.
Installation NotesMounts Up and Down
Warranty5 Year Limited - Fixtures
Packaging
Each UPC045923680922
Each Quantity1
Each Length (in.)5.12
Each Width (in.)5.12
Each Height (in.)8.27
Each Weight (lb.)2.38
Each Cube (CuFt.)0.1255
Pack TypeBox
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923680929
Case Quantity10
Case Length (in.)26.38
Case Width (in.)11.02
Case Height (in.)9.45
Case Weight (lb.)21.38
Case Cube (CuFt.)1.5898
No compatibility links for this item.
×
×
×

Precautions

No precautions available at this time.

×
California Prop 65 Warnings
Material Warning
Lead WARNING: This product can expose you to chemicals including Lead and lead compounds, which are known to the State of California to cause cancer or birth defects or other reproductive harm.
